Introduction
The GV Digital Surveillance System is an advanced, total system solution that provides continuous or scheduled monitoring and recording of video surveillance cameras. The system is based on PC
platform utilizing the latest digital video compression technologies.
The GV System as a whole is consisting of two key components: The video surveillance system and the
remote monitoring system.
-
Video Surveillance System: Consists the GV-Series video
capture card and the Main System Application. The
system is for the monitoring and recording of the video event from the cameras.
-
Remote Monitoring System: For viewing video surveillance
system's video event from a remote workstation over LAN or Internet.
Product Specification
|
|
Video Channel |
Video Device |
Recording Rate
(NTSC / PAL) |
Compression
Format |
Audio
Channel |
Real Time
Display Card |
| GV-600 |
4, 6, 8, 10, 12, 14, 16 |
Video Card |
30 / 25 |
Wavelet / MPEG4 |
1 |
Yes |
| GV-650 |
4, 8, 12, 16 |
Video Card |
60 / 50 |
Wavelet / MPEG4 |
2 |
Yes |
| GV-750 |
6, 9 |
Video Card |
90 / 75 |
Wavelet / MPEG4 |
3 |
Yes |
| GV-800 |
4, 8, 12, 16 |
Video Card |
120 / 100 |
Wavelet / MPEG4 |
4 |
Yes |
| GV-900 |
4, 8, 12, 16 |
Video Card |
240 / 200 |
Wavelet / MPEG4 |
4 |
Yes |
| GV-1000 |
4, 8, 12, 16 |
Video Card |
480 / 400 |
Wavelet / MPEG4 |
4 |
Yes |
Note:
1. The Real Time Display Card is not compatible with VIA chipset-based motherboards.
System Requirement
| |
GV-600 |
GV-650 |
GV-750 |
GV-800 |
GV-900 |
GV-1000 |
| OS |
Windows 2000 / XP |
| CPU |
PentiumIII 800 (minimum) |
| Memory |
128 MB (minimum) |
256 MB (minimum) |
| Hard Disk |
40 GB (min) |
80 GB (min) |
80 GB (min) |
80 GB (min) |
120 GB (min) |
160 GB (min) |
| VGA |
NVIDIA GeForce II MX200 32 MB (minimum) |
Note:
1. To use 640 x 480 recording feature Pentium 4 grade CPU is required.
2. Currently GV650/750/800/900/1000 card are not compatible with VIA series chipset motherboard.
Video Resolution
| |
640x480 |
640x480SW |
640x240 |
320x240 |
| GV-600 |
Yes |
Yes |
Yes |
Yes |
| GV-650 |
Yes |
Yes |
Yes |
Yes |
| GV-750 |
Yes |
Yes |
Yes |
Yes |
| GV-800 |
Yes |
Yes |
Yes |
Yes |
| GV-900 |
Yes |
Yes |
Yes |
Yes |
| GV-1000 |
Yes |
Yes |
Yes |
Yes |
|
Surveillance User's Manual V5.4
